Core Competitive Advantages
1 .Compliance Guarantee (Core Selling Point)
Fully complies with the Technical Specifications for Harmless Treatment of Diseased and Dead Animals (GB/T 16548-2020) and requirements of local environmental protection departments. The solid waste (convertible into raw materials for organic fertilizer) and waste gas emission after treatment meet national standards, and authoritative third-party inspection reports can be provided.
The equipment is equipped with a built-in "Compliance Recording System", which automatically stores the treatment time, temperature and pressure data of each batch, supports data export for filing, and avoids the risk of policy penalties.
2. Efficient and Convenient Operation
Treatment Efficiency: Single-batch processing capacity of 5-20kg (suitable for dogs, cats, poultry and small laboratory animals), treatment cycle of 90-180 minutes, 3-5 times higher efficiency than traditional deep burial /incineration.
Operation Threshold: 7-inch touch screen + preset programs (4 modes for dogs, cats, poultry and laboratory animals), one-key start without professional training; equipped with silent universal wheels, can be pushed by a single person (net weight ≤150kg), and flexibly placed in narrow spaces (such as storage rooms of pet hospitals).
3 .Safety and No Secondary Pollution
Dual Protection Design: The sterilization chamber is integrally formed with 304 stainless steel, equipped with double explosion-proof doors + automatic power-off at over-temperature (triggered when temperature>230℃); operators do not need to contact deceased pets, and feeding is completed through the sealed feeding port.
Waste Gas Purification: Adopts triple purification process of "activated carbon adsorption + UV photolysis + low-temperature plasma". The odor removal rate at the air outlet is ≥98%, no black smoke or irritating gas, meeting the emission requirements of residential /commercial areas.
Detailed Technical Parameters
| Parameter Category | Specific Specification | Remarks |
|---|
| Processing Capacity | 5-20kg per batch | Models with 8-30kg per batch capacity are customizable based on requirements |
| Core Sterilization Parameters | Temperature 180-220℃ (adjustable), Pressure 0.2-0.3MPa | High-temperature and high-pressure sterilization with a germicidal rate ≥99.99% |
| Treatment Cycle | 90-180 minutes per batch | Cycle duration varies with processing capacity |
| Power Supply Specification | 220V/50Hz or 380V/50Hz (optional) | 220V for household use, 380V for commercial use |
| Power Rating | 3.5-5.5kW | Full power during the heating phase, low power during the heat preservation phase |
| Overall Dimensions | L1200×W800×H1500mm | Floor area ≤1.2㎡, can be embedded in a standard storage room |
| Material | Inner tank: 304 stainless steel; Outer shell: cold-rolled steel plate with plastic spraying | Corrosion-resistant outer shell, suitable for humid environments |
| Control System | Touch screen + PLC intelligent control | Supports automatic fault alarm and data export |
| Operating Noise | ≤65dB | Equivalent to the volume of daily conversation, no disturbance to the surrounding environment |
| Weight | 120-180kg | Equipped with universal wheels, movable by a single person |
